PH7 Series 7"  Videoscope Tungsten Probe 360°
1 / 1
  • PH7 Series 7"  Videoscope Tungsten Probe 360°
PH7 Series 7" Videoscope Tungsten Probe 360°
Description:

- 7” (180mm) color LCD TFT display videoscope with high definition 720 x 480 pixel resolution (640 x 480 pixel in storage).
- Universal ball mount and kick stand at the back of controller can set the controller at the best viewing angle and flexible operation.
- Hand-strips and two sets of snapshot/ recording buttons provide better grip for left-handed and right-handed users.
- Sun screen protection is convenient for outdoor inspection.
- Powerful Li-ion battery with long operation time of 8 hours.
- Save your image and videos in SD card.





Download file
  • Introduction
  • Specification
  • Inspection Probe
  • Model
  • PH7 Series

    High Definition Video Inspection System




    Equipped with screen protection cover
    (* Waterproof and Dust-Proof of IP67 for optional camera probe / insertion tube)





    Rugged two handheld design and left / right hand control; standup support and tripod mount facility.


    SD card storage Mini USB 1.1/2.0 or AV out






    Customizable adapters compatible with J series probe.


    Package & Standard Accessories


    Application

  • Features Description
    LCD 7" LCD / 720 x 480 pixels
    Video Recording 640 x 480
    Snapshot 640 x 480
    Function Snap-shot while recording/replaying.
    Video Recording Format MPEG4 / ASF (640 X 480)
    Power Supply 100V – 240V AC in / 5V DC out
    Battery Rechargeable Li-Polymer Battery
    Battery lasting time 8Hrs (battery status in display)
    Operating Temperature 0 ~ 40 °C
    Storage Temperature -10 ~ 60 °C
    Dimensions 260 x 160 x 70 (mm)
    Weight 1.3 kg
  •




    360° Articulation VGA Probe 6mm (P series)

    Model: PHVS-60024_PHVS-60034
    Tip Diameter : Ø6mm
    Resolution : 640x 480
    Porbe Length : 1.5M / 3M
    Read More

  • Model Tip Dia. Resolution Length Articulation
    PH7-60024 Ø 6mm 640x480 1.5M 360˚(4Way)
    PH7-60034 Ø 6mm 640x480 3M 360˚(4Way)


  • Introduction

    PH7 Series

    High Definition Video Inspection System




    Equipped with screen protection cover
    (* Waterproof and Dust-Proof of IP67 for optional camera probe / insertion tube)





    Rugged two handheld design and left / right hand control; standup support and tripod mount facility.


    SD card storage Mini USB 1.1/2.0 or AV out






    Customizable adapters compatible with J series probe.


    Package & Standard Accessories


    Application

  • Specification
    Features Description
    LCD 7" LCD / 720 x 480 pixels
    Video Recording 640 x 480
    Snapshot 640 x 480
    Function Snap-shot while recording/replaying.
    Video Recording Format MPEG4 / ASF (640 X 480)
    Power Supply 100V – 240V AC in / 5V DC out
    Battery Rechargeable Li-Polymer Battery
    Battery lasting time 8Hrs (battery status in display)
    Operating Temperature 0 ~ 40 °C
    Storage Temperature -10 ~ 60 °C
    Dimensions 260 x 160 x 70 (mm)
    Weight 1.3 kg
  • Inspection Probe






    360° Articulation VGA Probe 6mm (P series)

    Model: PHVS-60024_PHVS-60034
    Tip Diameter : Ø6mm
    Resolution : 640x 480
    Porbe Length : 1.5M / 3M
    Read More

  • Model
    Model Tip Dia. Resolution Length Articulation
    PH7-60024 Ø 6mm 640x480 1.5M 360˚(4Way)
    PH7-60034 Ø 6mm 640x480 3M 360˚(4Way)
